HAAS UMC-750SS 5-AXIS VMC, 2018 – 15K RPM SPINDLE, TSC, WIPS, VIDEO
$144,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
X-Axis travel: 30″
Y-Axis travel: 20″
Z-Axis travel: 20″
Spindle nose to table top: 4-24″
Table size: 24.8″ x 19.7″
Table capacity: 660 Lbs.
Rotary axes rapid traverse rate: 150° per second
Rotary axes max. feed rates: 150° per second
Spindle motor: 30 HP (vector drive)
Spindle speed: 15,000 RPM
Spindle taper: CAT 40
Tool changer: 40 station
Max. tool size: 12 Lbs. / 3″ diameter w/ adjacent pockets full
Tool to tool: 2.3 seconds
Chip to chip: 3.2 seconds
Equipped with:
15k CAT40 Spindle
300psi through spindle coolant
Programmable coolant
40+1 tool changer
Wireless probing and tool setter
Internal transformer
Chip conveyor
8 auxiliary M-codes option
M-Fin option
Remote jog handle
Very clean machine in excellent shape mechanically and cosmetically. Nearly in like-new condition.
