ZC
8945633652
Fadal VMC 4020 HT CNC VMC, 2007
$9,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Taper Size: CAT 40
Speed Range: 75 – 10,000 RPM
Spindle Power: 15 HP
Travels:
X-Axis: 40″
Y-Axis: 20″
Z-Axis: 20″
Rapid Traverse Rates: 900 Inch Per Minute
Cutting Feed Rates: 400 IPM
Spindle Nose to Table (Min.- Max.): 4″ – 24″
Table:
Length: 48″
Width: 20″
Max Weight on Table: 3600 lbs
Air Required: 80 psi, 15 scfm
Power: 240v 3-Phase
Overall Dimensions: 122″ x 100″ x 100″ High
Weight (Approx) : 12500 lbs
Equipped With:
Fadal CNC88HS Control
MM Ball Screws
High Speed CPU
AC Motors
4th Servo Controller and Disconnect
Chiller
Rigid Tap
4 Meg Memory Expansion
