4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 2
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 3
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 4
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 5
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 6
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 7
BF
35872357644

4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013

$139,900.00

4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 2
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 3
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 4
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 5
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 6
4000 Watt Bystronic Bysprint 4020 Fiber Laser, 2013 - Image 7

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Fiber Lasers
Make: Bystronic
Model: Bysprint 4020 Fiber Laser
Year: 2013
Capacity: 4000 Watt
Machine Location: Upon Request
Stock #: 357644

Wattage: 4000

Cutting Area:
X: 160″
Y: 80″
X: 2.75″

Nominal Sheet Size:
X: 157″
Y: 78″

Maximum Positioning Speed Parallel Axis X,Y: 3937 Inch/Min
Maximum Simultaneous Positioning Speed: 5511 Inch/Min
Positioning Accuracy Pa*: +-0.004″
repeatability Ps*: +-0.002″
Maximum Workspace Weight: 3,484 Lbs

Max Sheet Thickness:
Steel: 0.75″
Stainless Steel: 0.625″
Aluminium: 0.625″
Brass: 0.312″
Copper: 0.312″

Machine Dimensions:
Length: 541″
Width: 262″
Height: 101″
Weight: 33,069 Lbs

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
