12″ x 13″ Kalamazoo DC 12A-NC Automatic Horizontal Double Column Programmable Saw, 2017
$21,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Capacity in Round Material: 12 1/4”
Capacity in Rectangular Material: 12 1/4” x 13 1/4”
Blade Speeds: 50-330 sfpm (15-110m/min)
Blade Width: 1 1/4”
Blade Length 12′ 3″
Blade Tension: Manual, With Indicator For Correct Tension
Blade Guides: Heavy Duty Carbide
Bandwheel Diameter: 16″
Vises: Hydraulic
Feeder Vise Single Stroke: 22”
Multiple Index: Unlimited
Feed Length Accuracy: Plus/Minus 0.005”
Minimum Remnant End: 2″
Material Work Height: 36 1/4″
Blade Drive: 5 HP
Hydraulic Drive: 2 HP
Coolant Motor: 1/4 HP
Coolant Tank: 20 Gal.
Materials: Carbon, Manganese, Nickel, Molybdenum, Silicon, Stainless, Steel, Aluminum
Weight: 3,800 lb.
Dimensions: 77″ (front) x 70″ (deep) x 77″ (high)
Power:
Coolant Capacity: 15 Gal.
Hydrualic Capacity: 2 2/4 Gal. Viscosity: 46
Voltage: 460 V 3 PH 60 Hz.
